Gaps in cable tray cover plate

Gaps in cable tray cover plates are necessary to accommodate thermal expansion and contraction of metal trays, prevent mechanical stress, and maintain long-term structural integrity.

Purpose of Gaps

Gaps in cable tray cover plates are primarily designed to allow for thermal expansion and contraction of the tray material. Metal trays, such as aluminum or steel, expand when heated and contract when cooled. Without adequate spacing, the trays can bend, warp, or damage mounting hardware, potentially compromising the cable system and safety of personnel.

For example, a 100-foot aluminum tray can expand or contract by approximately 2 inches with a 100°F temperature change.

Recommended Gap Sizing

The size of the gap depends on the material of the tray, the length of the run, and the expected temperature variation. Aluminum expands more than steel, so larger gaps are required for aluminum trays. Standard practice involves leaving a small, calculated gap between tray sections and using expansion guides to allow controlled movement while keeping the tray aligned.

Overly small gaps can cause trays to push against each other, while excessively large gaps may reduce system stability.

Installation Considerations

Expansion Joints: Use expansion joints or splice plates designed to accommodate movement without stressing the tray or cover. Cover Plate Alignment: Ensure cover plates are properly seated but not tightly fixed across gaps, allowing for thermal movement. Environmental Factors: Outdoor installations or areas with high temperature fluctuations require careful gap calculation to prevent water ingress or mechanical stress.

Compliance: Follow NEMA VE 2 standards and manufacturer guidelines to ensure gaps meet safety and performance requirements.

Additional Notes

Solid bottom trays with covers may also require weep holes to prevent moisture accumulation, especially in humid or outdoor environments. Properly sized gaps combined with these design features help maintain cable protection, EMI/RFI shielding, and system reliability. In summary, gaps in cable tray cover plates are a critical design feature that ensures safe, durable, and compliant cable management by accommodating thermal movement and preventing mechanical damage.

Proper calculation, material selection, and adherence to standards are essential for optimal performance.
