Can branch cables be run in cable trays

Fiber and communications infrastructure knowledge brief Published 30 Jul 2023

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Branch cables can be run in cable trays if they are tray-rated and comply with NEC 392 requirements, including support, fill limits, and distance restrictions.

NEC Compliance and Cable Types

The National Electrical Code (NEC) governs cable tray installations under Article 392. Only tray-rated cables (such as TC or MC cables) are permitted in cable trays, and they must be UL listed for tray use. These cables are designed to withstand heat, moisture, and mechanical stress typical in tray applications.

Branch cables leaving the tray must be exposure-rated (ER) if they extend beyond the tray for up to six feet, provided they are properly supported and secured.

Branch Cable Extensions

Branch cables can exit the main tray to supply equipment or devices, but NEC limits the distance they can run unsupported. Typically, branch cables may extend up to six feet from the tray if they are ER-rated and properly supported. This ensures mechanical protection and prevents strain on the cable connections.

Tray Fill and Separation

Cable trays have fill capacity limits based on cable diameter, type, and tray configuration. Overfilling can cause overheating, restricted airflow, and maintenance difficulties. Power and data cables must be separated to prevent interference, and proper support must be provided for all cables, including branch runs.

Support and Grounding

Branch cables must be supported at regular intervals, and metallic trays must be grounded and bonded according to NEC 392. 60. This ensures electrical continuity and safety, allowing the tray to serve as an equipment grounding conductor if properly installed.

Best Practices

Use ladder or ventilated trough trays for better support and airflow. Ensure branch cables are mechanically secured and do not exceed the six-foot unsupported limit. Verify tray fill calculations to maintain safe ampacity and prevent overheating.

Follow manufacturer specifications and NEC guidelines for cable type, spacing, and support. In summary, branch cables can be run in cable trays if they are tray-rated, properly supported, comply with fill limits, and adhere to NEC requirements for grounding and separation. Proper planning ensures safety, code compliance, and long-term reliability of the electrical system.
