Does a network cable tray need to be grounded

Fiber and communications infrastructure knowledge brief Published 25 May 2026

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Yes, all metallic cable trays must be grounded to ensure electrical safety, even if they are not used as the primary equipment grounding conductor (EGC).

NEC and Safety Requirements

According to the National Electrical Code (NEC) Article 392, metallic cable trays must be bonded and connected to the building's grounding system to prevent electrical shock and equipment damage. Grounding ensures that any stray currents or fault conditions are safely diverted to earth, reducing the risk of fire, shocks, or equipment malfunction. Non-metallic trays, such as fiberglass or plastic, do not require grounding but may need bonding for lightning protection or EMI mitigation in certain installations.

Methods of Grounding

Using the Tray as an EGC: In qualifying facilities, the metallic tray itself can serve as the equipment grounding conductor if it meets minimum cross-sectional area requirements and is electrically continuous. Separate Grounding Conductor: A dedicated grounding wire (minimum #4 AWG) can be run along the tray or inside it, bonded to each tray section with clamps or connectors. Bonding Jumpers: Where tray sections are joined, bonding jumpers ensure electrical continuity across gaps, maintaining a safe path for fault currents.

Best Practices

Avoid placing bare copper conductors in aluminum trays to prevent electrolytic corrosion; use insulated conductors with exposed ends at bonding points. Ensure all tray sections, side rails, and connectors are electrically continuous and bonded back to the power source. Maintain proper separation between power and data cables to reduce electromagnetic interference while grounding the tray.

Summary

Grounding metallic network cable trays is mandatory for safety and code compliance. Whether the tray serves as the EGC or a separate conductor is used, proper bonding and continuity are essential to protect personnel and equipment from electrical faults. Non-metallic trays do not require grounding but may need bonding for specific applications like lightning protection or EMI control.
