Huijue 288-core optical cable diameter

Fiber and communications infrastructure knowledge brief Published 22 Dec 2025

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

The Huijue 288-core optical cable typically has an overall diameter of approximately 18–20 mm, with individual tubes measuring 2. 5 mm in diameter.

Cable Construction

The Huijue 288-core optical cable is a multi loose tube design containing 12 tubes, each with 24 fibers, totaling 288 fibers. Each tube has a diameter of 2. 5 mm and is stranded around a central strength member, often reinforced with glass yarns or a steel tape for rodent protection and mechanical strength.

The cable is usually sheathed with a Low Smoke Zero Halogen (LSZH) or polyethylene jacket, suitable for indoor/outdoor installations.

Overall Diameter

The overall cable diameter depends on the construction type (armored vs. non-armored, gel-filled vs. dry core). For a standard 12-tube, 288-fiber loose tube cable, the finished cable diameter is typically in the range of 18–20 mm. This includes the central strength member, stranded tubes, water-blocking elements, and outer jacket.

Armored versions with corrugated steel tape may be slightly larger due to the added protective layer. Installation ConsiderationsIndoor/Outdoor Use: Suitable for ducts, tunnels, and direct burial. Mechanical Strength: Designed to withstand tensile loads and crush resistance during installation and operation.

Fiber Management: Tubes can be easily accessed for splicing or termination, and color-coded fibers simplify identification. In summary, the Huijue 288-core optical cable has 2. 5 mm tubes and an overall diameter around 18–20 mm, making it compatible with standard high-density backbone and data center installations.
