Progress of the Chengdu-Kunming Railway Second Line Bridge Construction

Fiber and communications infrastructure knowledge brief Published 01 Jan 2024

Prepared for preliminary research by the ROGER FIBRE knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

The Chengdu-Kunming Railway second line has achieved major bridge construction milestones, including the completion of the Mianshan Double Track Bridge and the Panzhihua Jinsha River Bridge, overcoming complex terrain and technical challenges.

Key Bridge Construction Milestones

Mianshan Double Track Bridge: On May 11, 2026, the Mianshan Double Track Bridge, designed by China Railway Second Institute and constructed by China Railway 21st Bureau Group, successfully completed a full bridge installation with a 10,000-ton continuous beam spanning the existing line through a swivel mechanism, marking a significant engineering achievement in the expansion project. Panzhihua Jinsha River Bridge: This bridge features a 208-meter main span, making it the largest prestressed-concrete low-tower cable-stayed bridge in China. It is the first in the country to adopt upper cable beam anchor block technology, and it incorporates China's largest tonnage hyperboloid spherical bearing along with a shear tenon vibration isolation system, ensuring stability and resilience in a challenging seismic and geological environment.

Engineering Challenges

The railway passes through extremely rugged terrain, including mountains, rivers, and fault zones. Key challenges included: Constructing tunnels through complex strata, such as the 12. 4 km Yakou Tunnel crossing six sets of strata and seven regional faults, and the 12.

76 km Ranjiawan Tunnel through the fragile Xigeda stratum. Building bridges over large rivers and reservoirs, including the Majiatian tailings reservoir and artificial lakes, with minimal clearance above tunnel tops, requiring precise engineering. Ensuring structural safety in areas with high-rise buildings and densely populated zones.

Overall Project Impact

The second line of the Chengdu-Kunming Railway, including these bridges, forms part of the 915-kilometer double-track line that reduces travel time between Chengdu and Kunming to 7. 5 hours and significantly improves connectivity to cities like Xichang and Panzhihua. The completion of these bridges enhances the railway's capacity, safety, and operational efficiency, supporting regional economic development and integration into China's southwestern railway network.

The project demonstrates advanced engineering solutions in bridge construction, tunnel design, and vibration isolation, setting new standards for railway infrastructure in challenging terrains.
