Distance between horizontally laid cable tray supports

The typical horizontal support span for cable trays ranges from 1. 5 meters to 3 meters, depending on tray type, load, and installation standards.

Recommended Support Spacing

For straight horizontal runs, cable trays should be supported at intervals that prevent sagging and maintain structural integrity. The general guidelines are: Standard horizontal span: 1. 5 to 3 meters between supports for most cable tray types, allowing easy access and maintenance.

NE

C compliance: Supports should not exceed 5 feet (approximately 1. 5 meters) for ladder-type trays, with an ideal run length between supports of 4 to 6 feet (1. 2 to 1.

8 meters) depending on load and manufacturer specifications. Bends and corners: Install one support on each side of the bend, arranged symmetrically to prevent stress on the tray and cables. Heavy loads or wide trays: Reduce support spacing to maintain stability and prevent deflection, especially for trays wider than 42 inches or carrying dense cable bundles.

Additional Considerations

Hanging rod supports: Minimum diameter of 8 mm is recommended for stability. Fixed supports: Place at tray ends, corners, T-junctions, and spans over 30 meters to distribute weight evenly. Cable securing: Cables should be tied down at the start, end, turns, and every 3 to 5 meters along straight sections to prevent movement and mechanical strain.

Material and fire safety: Supports must be fire-resistant to prevent premature failure in case of fire.

Summary

The horizontal support distance depends on tray type, load, and installation environment, but 1. 5 to 3 meters is typical, with closer spacing required for heavy loads, wide trays, or critical installations. Always follow manufacturer guidelines and applicable codes such as the NEC or BS 7671 to ensure safety and compliance.
